Description
Specifications
Input Voltage 9 to 16 Vdc
Current Consumption 150 mA maximum
PGM Output 1
Keypad Zone Input 1
Connections 4-wire communication bus
Operating Temperature -10 to 55 °C (14 to 131 °F)
Dimensions 12.3 x 14.4 x 3.2 cm (4.9 x 5.7 x 1.3 in.)
In-field firmware upgradeable via 307USB and InField software
Display time of 12 or 24 hour format
Features
- Beautiful new design
- Zone alarm display: the zones in alarm are shown until the system is disarmed
- In-field firmware upgradeable via a CONV4USB
- Simplified end-user remote control programming
- Supports EVO192 and EVOHD
- 32-character blue LCD with programmable labels (via Memory Key, NEware or Module Broadcast feature)
- Available in Bulgarian, Croatian, Czech, Dutch, English, French, German, Greek, Hebrew, Hungarian, Italian, Polish, Portuguese, Russian, Slovak, Slovenian, Spanish, Swedish, Turkish, Lithuanian, Finnish and Turkish)
- Assign to one or more partitions
- 1 addressable zone and 1 PGM output
- Independently set chime zones
- 14 one-touch action buttons
- 3 keypad-activated panic alarms
- Adjustable backlight, contrast and scroll speed
- Display time using the 12Hr or 24Hr format
